Explore the World’s Most Powerful Shortwave Transmitter – Where Connectivity Knows No Limits!

WBCQ is a shortwave station operating from Monticelle in Northern Maine, North America that transmits a wide (perhaps the widest) variety of programs on legal shortwave

The high-power antenna offers different radiation patterns and an antenna gain of up to 23 dB and uses a technology characterized by a single-shaft structural design,” according to Cestron International the installer of the antenna in a project summary.

The tubular shaft has a diameter of four meters. Its support design will absorb static and dynamic forces originating from the antenna components, allowing the system to function even under extreme weather conditions, according to Cestron.

The antenna consists of low- and high-band array antennas, positioned back to back, each equipped with a reflector screen, allowing WBCQ to access all shortwave frequency bands between 6 MHz and 26 MHz.

A computer-controlled and -monitored system manages rotation and turns toward the coverage area using the shortest possible path. “Intelligent drive control ensures the large rotating part of the structure is jolt-free, starting and braking to standstill with a high rotation speed of 1.2 degrees per second and a positioning accuracy of < 1 degree,” according to Cestron.

At 500 kW with an ERP of 20 MW, it is one of the most powerful shortwave stations in the USA.

See below QSL card Garry received from them.
